McIntosh C29

The McIntosh C29 is a highly regarded solid-state stereo preamplifier manufactured from 1978 to 1985, drawing a modest 45 watts of line power from the wall. The C29 features an integrated, high-current headphone amplifier stage that outputs 0.75 volts into an 8-ohm load via dedicated dual front-panel jacks. For core system routing, its main preamp output delivers a rated 2.5 volts with a remarkably low source impedance of less than 100 ohms, designed to interface seamlessly into any standard 10,000-ohm or greater power amplifier. Vinyl playback is anchored by an ultra-quiet phono stage operating at an input impedance of 47,000 ohms and dropping hum to an exceptional -90 dB. Critical signal attenuation is governed by a custom-designed, 32-step master volume control that utilizes electronically trimmed resistance elements to guarantee channel tracking within a razor-sharp 1 dB across its entire 70 dB range. Finished in McIntosh's timeless aesthetic, the 21-pound chassis features a back-lit black glass faceplate accented with anodized aluminum end caps, push-button command indicators, dual concentric step-switch tone controls, and a comprehensive 5-position mode selector.
